Toroidal Coil Structure Dry Type Transformer SCB12 Industrial Electrical Transformer

Product Details:
Place of Origin: China
Model Number: SCB12
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 500-30000
Packaging Details: wood
Delivery Time: 15 DAYS
Payment Terms: LC T/T
Supply Ability: 5000 pieces/year
Contact Now

Detail Information

Phase: Three Coil Structure: Toroidal
Frequency: 50/60Hz Rated Capacity: 30-3000kva
Type: Dry-type Color: Customized Or Red
High Light:

cast resin dry type transformer


power distribution transformer

Product Description



SCB12 dry transformer



·Product introduction

Dry-type transformer has the advantages of large short-circuit resistance, little maintenance work, high operation efficiency, small dimension and low noise, which is commonly used in places with high requirements of fireproof and explosion-proof. This type transformer is widely used in local lighting, high buildings, airports, docks, CNC machinery and others. Its cooling methods are divided into natural air cooling (an) and forced air cooling (AF). The transformer can operate continuously for a long time under rated capacity under natural air cooling. Output capacity of the transformer can increase by 50% under forced air cooling. It is suitable for intermittent overload operation or emergency overload operation. Due to the load loss and impedance voltage increase significantly when overload, it is not suitable for long time continuous overload operation.


Toroidal Coil Structure Dry Type Transformer SCB12 Industrial Electrical Transformer 0

·Structural features

1. Safe, fireproof and pollution-free;

2. Advanced technology, high mechanical strength, strong short-circuit resistance, small partial discharge, good thermal stability, high reliability and long service life;

3. Low loss, low noise, obvious energy-saving effect, maintenance-free;

4. Good heat dispersion and strong overload capacity. Forced air cooling can improve operation capacity ;

5. Good moisture-proof performance, suitable for high-humidity and other harsh environment;


6. The dry-type transformer can be equipped with complete temperature detection and protection system. The intelligent signal temperature control system, with the function of alarm and circuit trip, can automatically detect and display the working temperature of the three-phase winding, automatically start and stop the fan.

7. Small dimension, light weight, small floor area and low installation cost.



·Order instructions:

1. The customer needs provide main parameters of the transformer (input and output voltage, capacity, loss, etc.)

2. Other customer requirements
