Three Phase Electrical Substation Box Stainless Steel Material IEC60076 Standard

Product Details:
Place of Origin: China
Model Number: ZGS
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 2000-200000/piece
Packaging Details: wooden case
Delivery Time: 30 days
Payment Terms: LC T/T
Supply Ability: 5000 pieces/year
Contact Now

Detail Information

Material: Stainless Steel Standard: IEC60076
Coil Structure: Toroidal Usage: POWER
Name: American Prefabricated Substation Model Number: FZB-35/0.6-2000
Phase: Three Color: Customized Or Gray
High Light:

power distribution substation


electrical distribution substation

Product Description

Zgs Model Combined Type 11kv 22kv 33kv 415V 400kVA American transformer,
Product Feature
Small volume, compact structure, reliable power supply and easy for installation; it can
realizesingle power supply, double power supply, or ring net supply, with double-fuse
protection, low running cost.
The casing surface is treated by electrostatic painting and has good wearing resistance.

It is applicable to both ring network and single/double power supply, is convenient for
shifting, and can enhance the reliability of power supply. The transformers adopts
S11 series spiral core, non-excited voltage regulation, full-enclosed type, featuring energy
saving and low noise. The amorphous alloy transformer is also available if required by
clients. HV load switches and protective fuse are placed in oil filled iron tank, and the tank
is of full-enclosed structure. The LV room is provided with watt-hour meters, voltmeter,
and breakers of four outgoing lines, reactive power compensation can also be provided if
necessary.It uses S11 series spiral core transformer amplifier, its idle loss is 30%-40% lower
than S9, and noise 7-10Db lower than S9.

Item Unit Parameter
HV LV Transformer
RatedVoltage KV 12 0.4 12/0.4
RatedCurrent A 125 2000
RatedFrequency Hz 50/60
RatedCapacity KVA     s1250
RatedShort-timePowerFrequencyWithstandVoltage KV 42 2.5 35
RatedLightninglmpulseWithstandVoltage KV 75 8 75
RatedShortCircuitDrop-outCurrent KA 31.5
RatedShortCircuitClosingCurrent KA 80
RatedPeakWithstandCurrent(Groundloop) KA 31.5
28RatedShort-timeWithstandCurrent(Groundloop) KA 12.5
ProtectionDegree   IP54


Three Phase Electrical Substation Box Stainless Steel Material IEC60076 Standard 0
Prdduct structure
♦ American box transformer is divided into two parts: Transformer Part and control cabinet
part. The transformer part is fully sealed structure. Insulating oil can be high burning point
or commonoil. The control cabinet is further divided into a high-pressure chamber and a
low-pressure chamber
♦ The high-pressure Chamber is equipped with: high-voltage cable plug, lightning arrester,
load switchhandle, non-excitation disconnecting switch handle, insert fuse, pressure relief valve,
thermometer, manometer, oil level meter, oil filling plug, oil discharge valve, etc. Load switch,
non-excitation tap changer, plug-in fuse and so on are immersed in transformer oil together with
the transformer core.
♦ The low-voltage side can be equipped with air circuit breaker, current transformer, current
master meter,ammeter and voltmeter.
Three Phase Electrical Substation Box Stainless Steel Material IEC60076 Standard 1
