Custom SCB10 Dry Type Power Transformer Dry Cast Resin Transformers ISO9001

Product Details:
Place of Origin: China
Brand Name: HENGFENGYOU
Certification: ISO IEC CB COC KEMA SNI SABS CCC
Model Number: scb10
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 200-200000/piece
Packaging Details: wooden case
Delivery Time: 15 DAYS
Payment Terms: LC T/T
Supply Ability: 5000 pieces/year
Contact Now

Detail Information

Model Number: SCB11 500kVA/10KV/400V Phase: Three
Type: Dry-type Certification: ISO9001
Frequency: 50/60Hz Low Voltage: 0.4kV~0.433kV
High Voltage: 6kV~11kV Code For Performance Level: 10
Highlight:

cast resin dry type transformer

,

power distribution transformer

Product Description

Custom SCB10 20kva 50kva 150kva 350kva 400kva 500kva 3-phase cast resin dry type electric transformer



Product overview


Performance index of dry-type transformer produced by the Company meets various standards and it is demonstrated by users to have reliable operation and reach the national advanced level. This series of products are manufactured by using advanced foreign technology and design drawings and technical documents are complete, accurate and clear. The Company has advanced production equipment, stable manufacturing process and complete testing methods to provide solid guarantee for producing high-quality products.



MainperformanceparametersforSC(B)106kV-11kVseries
Model Rated
capacity
(KVA)
Connection
symbol
Voltagecombination(KV) No-load
loss(W)
Load
loss(W)
No-load
current
(%)
Shortcircuit
impedance(%)
High-
voltage
Tapping
range
Low-
voltage
SC10-30 30 Yyn0
or
Dyn11
6
6.3
6.6
10
10.5
11
+5%
+2*2.5%
or
+3-1
*2.5%
0.4
0.415
0.433
190 710 2.4 4
SC10-50 50 270 1000 2.4
SC10-80 80 370 1380 1.8
SC10-100 100 400 1570 1.8
SC10-125 125 470 1850 1.6
SCB10-160 160 550 2130 1.6
SCB10-200 200 630 2530 1.4
SCB10-250 250 720 2760 1.4
SCB10-315 315 880 3470 1.2
SCB10-400 400 980 3990 1.2
SCB10-500 500 1160 4880 1.2
SCB10-630 630 1350 5880 1
SCB10-630 630 1300 5960 1 6
SCB10-800 800 1520 6960 1
SCB10-1000 1000 1770 8130 1
SCB10-1250 1250 2090 9690 1
SCB10-1600 1600 2450 11730 1
SCB10-2000 2000 3050 14450 0.8
SCB10-2500 2500 3600 17170 0.8
SCB10-1600 1600 2450 12900 1 8
SCB10-2000 2000 3050 15890 0.8
SCB10-2500 2500 3600 18890 0.8



Custom SCB10 Dry Type Power Transformer Dry Cast Resin Transformers ISO9001 0





Product usage
SC (B) 10 epoxy resin cast dry-type transformer is manufactured according to standard of Dry-type Power Transformer, characterized with low performance loss, good energy saving effect, economic operation and no maintenance. In addition to high process structure metal, short-circuit resistance and lightning impulse level, it is still characterized with flame retardant, dampproof, dust-proof and low noise, which can be connected to load center. It is widely used in high-rise buildings, airport, station, wharf, power plant, transformer substation, etc., especially applicable to be used in places with high fire protection requirements for flammable and combustible materials.
Standard transformer produced by the Company has no case, with the protection level of IP00, and case with the protection level of IP20 and IP23 can be provided as required by clients. Housing is made of such materials as common steel plate, corrosion resistant plate and aluminum alloy and then treated with acid pickling, phosphorization and plastics spraying according to the requirements of clients. Temperature control indicator and load recorder are installed on the low-tension side of the housing, convenient for observation and safe and reliable.



Custom SCB10 Dry Type Power Transformer Dry Cast Resin Transformers ISO9001 1





Company profile



Qingdao Hengfengyou Electrical Engineering Co. , Ltd. is one of the large-scale electric complete
sets of manufacturers in China, specializing in oil-immersed transformers, dry-type transformers,
high-voltage Cabinets, low-voltage cabinets and substation manufacturing specialized electrical
enterprises. The company is located in the beautiful coastal city of china-qingdao. The company
has a registered capital of 10 million yuan, 20 senior technical personnel, more than 500 employees,
and a sound sales and service system, annual output value of US $1 billion, the products sell well at
home and abroad.
