Product Details:
|
|
| Place of Origin: | China |
|---|---|
| Brand Name: | HENGFENGYOU |
| Certification: | ISO IEC CB COC KEMA SNI SABS CCC |
| Model Number: | ZGS |
|
Payment & Shipping Terms:
|
|
| Minimum Order Quantity: | 1 |
| Price: | 2000-200000/piece |
| Packaging Details: | wooden case |
| Delivery Time: | 30 days |
| Payment Terms: | LC T/T |
| Supply Ability: | 5000 pieces/year |
|
Detail Information |
|||
| Material: | Stainless Steel | Standard: | IEC60076 |
|---|---|---|---|
| Coil Structure: | Toroidal | Usage: | POWER |
| Name: | American Prefabricated Substation | Model Number: | FZB-35/0.6-2000 |
| Phase: | Three | Color: | Customized Or Gray |
| High Light: | power distribution substation,electrical distribution substation |
||
Product Description
Box Substation Zgs Solar Photovoltaic Wind Power Substation Box Substation
Substation, Prefabricated Substation, Combine
Product advantage
● Low loss, noise and temperature rise; super nameplate capacity and high load bearing; high
resistance of sudden short-circuit capacity
● Full enclosed and insulated structure, stable and reliable operation
● Flexible wiring with easy conversion, which could be both connected to the terminal
system and looped network system; more chance of power supply.
● Easy operation and maintenance; short-term production phase; low construction costs
| Item | Unit | Parameter | ||
| HV | LV | Transformer | ||
| RatedVoltage | KV | 12 | 0.4 | 12/0.4 |
| RatedCurrent | A | 125 | 2000 | |
| RatedFrequency | Hz | 50/60 | ||
| RatedCapacity | KVA | s1250 | ||
| RatedShort-timePowerFrequencyWithstandVoltage | KV | 42 | 2.5 | 35 |
| RatedLightninglmpulseWithstandVoltage | KV | 75 | 8 | 75 |
| RatedShortCircuitDrop-outCurrent | KA | 31.5 | ||
| RatedShortCircuitClosingCurrent | KA | 80 | ||
| RatedPeakWithstandCurrent(Groundloop) | KA | 31.5 | ||
| 28RatedShort-timeWithstandCurrent(Groundloop) | KA | 12.5 | ||
| ProtectionDegree | IP54 | |||
Prdduct structure
ZGS series combined transformers also called American transformers and are series of products
as required by the construction development and transformation of rural and urban grid. It is a kind
of transformer combined by auxiliary equipment including the body of transformer, switchgear,
fuse, disassembling switches, low-voltage power distribution unit, which can meet the requirement
of configurations such as electric power measurement, reactive compensation and low-voltage shunt.
The ZGS combined transformer, in AC 50HZ, 6-10KV network, whose nominal capacity is 63-1600KVA,
is an independent set of transformation and distribution device, which can be both applied to outdoor
and indoor, generally used in industrial zone, urban residential district, commercial center, high-rise
buildings and temporary construction sites.
