Usage: | Power Electronic Distribution Transformer | Coil Number: | Double Winding |
---|---|---|---|
Phase: | Three | Rated Capacity: | 30-4000kva,2500kVA |
Product Name: | 3 Phase Dry Type Electrical Transformer 300kva | Material: | EXPOY RESIN,Copper |
Efficiency: | High Efficiency | ||
High Light: | cast resin dry type transformer,dry cast resin transformers |
Product Description
Encapsulated dry transformer 500kva 800kva 10kv/400v 3 phase dry type isolation transformer epoxy cast resin transformer
Product introduction
Dry-type transformers are widely used in local lighting, high-rise buildings, airports, docks CNC machinery and other places, simply that dry-type transformers refers to the core and the winding is not immersed in the insulating oil transformer.
We can make Epoxy Resin Cast Dry-Type Transformer , SC(B)10,SC(B)11-30~2500/10 Series of Epoxy Resin Cast Dry-Type Distribution Transformer , SC(B)10-30~2500/35 Series of Epoxy Resin Cast Dry-Type Distribution Transformer , SC(B)10-30~2500/35 Series of Epoxy Resin Cast Dry-Type Distribution Transformer , SC(B)H15-100~2500/10 Series of Amorphous Alloy Resin Casting Dry-type Transformer , SC(B)10-30~2500/20(10) (Achieving voltage change between 20kV and 10kV) Series of Epoxy Resin Cast Dry-type Distribution Transformer , CKSC Series of Dry-Type Iron Core Reactor , S11-M-30~2500/10 Series of Fully Sealed Oil-immersed Distribution Transformer , S13-M·RL-30~1600/10 Series of Three-dimensional Coil Core Oil-immersed Transformer , S(B)H15-M-30~1600/10 Series of Amorphous Metal Distribution Transformer , s(z)11-630~31500/35 Series of On-load Regulation Oil-immersed Transformer , Phase-shifting rectifier transformer...
Characteristics:
Low energy consumption:The adoption of isotropic soft magnetic material generates low magnetization power, high electrical resistivity and low eddy current consumption. The no-load loss and current of the core made of amorphous alloy are very low, only 1/3 of that of silicon steel sheet.
Strong corrosion resistance: the amorphous alloy core is fully wrapped by resin and high temperature resistant silica gel,n which effectively prevent corrosion and falling off of amorphous alloy fragments, and also provide better protection for the core and coil.
Low noise. Improvement of the structure of iron core and coil and adoptionof special noise -reduction materials greatly reducing the operation noise.
Strong short-circuit resistance. This product adopts three-phase five-column structure, and the iron core is protected by frame structure. Featured by low temperature-rise and strong heat dissipation, this productcan workby 150% rated load under air cooling condition. Perfect temperature control protection system is applied to provide reliable guarantee for safe operation of transformer
1. Transformer normal service conditions
The height above the sea level is below 1000m;
Highest air temperature +40ºC;
Highest daily average air temperature+30ºC;
Highest annual average air temperature +20ºC;
Lowest outdoor air temperature -25ºC.
(defines in detail when transformer in special service conditions )
2. Dry type transformer Technical parameters(First-level energy efficiency grade)
Rated capacity (kVA) |
Voltage combination | Connected group label |
No-load loss (W) |
Load loss (W) | No-load current (%) |
Impedance voltage (%) |
||||
High voltage (kV) |
(%) tap range |
Low Voltage (kV) |
||||||||
130°C(B) | 155°C(F) | 180°C(H) | ||||||||
100°C | 120°C | 145°C | ||||||||
50 | 20 22 24 |
±2X2.5 ±5 |
0.4 | Dyn11 YynO |
340 | 1160 | 1230 | 1310 | 2.0 | 6.0 |
100 | 540 | 1870 | 1990 | 2130 | 1.8 | |||||
160 | 670 | 2330 | 2470 | 2640 | 1.5 | |||||
200 | 730 | 2770 | 2940 | 3140 | 1.5 | |||||
250 | 840 | 3220 | 3420 | 3660 | 1.3 | |||||
315 | 970 | 3850 | 4080 | 4360 | 1.3 | |||||
400 | 1150 | 4650 | 4840 | 5180 | 1.1 | |||||
500 | 1350 | 5460 | 5790 | 6190 | 1.1 | |||||
630 | 1530 | 6450 | 6840 | 7320 | 1.0 | |||||
800 | 1750 | 7790 | 8260 | 8840 | 1.0 | |||||
1000 | 2070 | 9220 | 9780 | 10400 | 0.85 | |||||
1250 | 2380 | 10800 | 11500 | 12300 | 0.85 | |||||
1600 | 2790 | 13000 | 13800 | 14800 | 0.85 | |||||
2000 | 3240 | 15400 | 16300 | 17500 | 0.7 | |||||
2500 | 3870 | 18200 | 19300 | 20700 | 0.7 | |||||
2000 | 3240 | 16800 | 17800 | 19100 | 0.7 | 8.0 | ||||
2500 | 3870 | 20000 | 21200 | 22700 | 0.7 |
Note: Due to continuous product improvement, the dimensions provided in this sample are for reference only. If necessary, our company can design and produce according to user requirements. Please contact the company in time.
· Order instructions:
1. The customer needs provide main parameters of the transformer (input and output voltage, capacity, loss, etc.)
2. Other customer requirements
